A 50 kg or 80 kg label is not enough to establish a comparable Mumbai price: reach, gripper weight, balancing method, mounting, installation, and site services can change the quotation substantially. By the end, you will be able to define the machine you need, compare equipment-only and installed prices, and reject quotes that do not prove payload, safety, and service scope.
Key takeaways
- Request equipment-only and installed, commissioned prices.
- Match rated capacity to the heaviest real load, not the average load.
- Compare reach, stroke, gripper, controls, mounting, GST, and training.
- Include installation, maintenance, safety documentation, and downtime in total cost.
What a DRA 50 or 80 kg manipulator quotation should include
For a dra manipulator price in mumbai comparison, request two figures: equipment-only and installed, commissioned. A headline price is incomplete without the arm’s reach, vertical stroke, working envelope, balancing method, gripper, controls, mounting structure, freight, GST, and operator training.
Your quotation checklist should include:
- The DRA-50 or DRA-80 manipulator arm, rated payload, load chart, allowable moment, working radius, vertical travel, and permitted load-centre offset.
- A gripper or attachment designed for the component’s dimensions, centre of gravity, contact surfaces, and release method.
- Pneumatic, electric, or servo-assisted balancing equipment, including air filtration and regulation, encoders, drives, safety circuits, and required utilities.
- Floor or column foundation, structural support, anchor hardware, guarding, cables, hoses, and control pendant.
- Freight to your Mumbai site, installation, alignment, commissioning, functional testing, and operator training.
- GST shown separately, with payment terms, delivery period, warranty, and exclusions stated in rupees.
- Preventive-maintenance intervals, calibration or load-testing support, seal and wear-part availability, and local service response time.
For industrial manipulator cost in mumbai, compare the complete installed figure rather than the arm alone. Ask the supplier to state whether the payload includes the gripper: a 50 kg workpiece plus a 10 kg tool already requires more than a 50 kg rated capacity, especially at extended reach.
A supplier that cannot provide these inclusions is not offering a comparable quotation.
How to decide between DRA-50 and DRA-80 for your actual load
Choose DRA-50 only when the complete moving load remains within its capacity at the furthest reach. Add the workpiece, gripper, adapter plate, hoses, and any tooling before comparing models: a 50 kg component plus a 10 kg gripper already exceeds a 50 kg rating.
| Option | Check before selecting | Consequence |
|---|---|---|
| DRA-50 | Total load, centre of gravity, reach, stroke, orientation, acceleration, and cycle rate fit its load chart | Lower purchase and operating cost, but less margin for offsets or future tooling |
| DRA-80 | The same values remain within the chart with reserve capacity | Higher cost, but better tolerance for long tools, eccentric loads, and repeated duty |
Do not accept “50 kg” or “80 kg” as usable capacity at every position. Request a capacity-versus-reach chart showing maximum load, working radius, vertical travel, allowable moment, permitted load-centre offset, and payload at your specified wrist orientation. A long or offset workpiece creates torque that can reduce the allowable load before the scale weight changes.
Give suppliers the workpiece dimensions, centre of gravity, pick and place heights, rotation angle, maximum reach, acceleration, handling speed, and cycles per hour. That information makes a quoted dra 50 kgs manipulator price comparable with an 80 kg alternative.
Before purchase, run the actual workpiece with the proposed gripper. Test pickup, full-reach transfer, placement accuracy, repeated cycles, safe load retention, and the response to lost air or power. Catalogue capacity alone cannot prove suitability.
Check the working envelope, controls, attachment, and alternatives
A manipulator will outperform a hoist, lift table, or robot only if its complete working envelope matches the job. Check the maximum reach, vertical stroke, pick and place heights, rotation angle, approach direction, and clearance at every point; a tool that reaches the load but strikes a fixture is not fit for purpose.
- Record the workpiece length, width, weight, centre of gravity, and any offset from the arm’s wrist. A 50 kg component with a long offset creates a larger moment than a compact 50 kg component and can overload the arm at full reach.
- Specify the full lifted mass: workpiece, gripper, quick-change coupling, hoses, magnets, vacuum equipment, and sensors. A 50 kg load plus a 10 kg attachment needs capacity above 50 kg.
- Test the complete pick-transfer-rotation-place cycle at the required cycle rate, acceleration, and handling speed. Slow, cautious movement during a demonstration can hide poor performance in production.
- Confirm the control method: spring or pneumatic balance, electric assistance, pendant controls, dead-man switches, speed control, anti-drop protection, and part-presence sensing.
- Require the attachment to hold the actual surfaces and orientation. A generic hook is not equivalent to a vacuum frame, lifting magnet, clamp, or machine-tool interface.
- Compare alternatives against the same task. Use a hoist for occasional vertical lifting, a lift table for height adjustment, a robot for repeatable high-volume paths, and a manipulator for frequent operator-guided movement with ergonomic positioning.
Choose the DRA-50 or DRA-80 only after a loaded trial proves reach, balance, rotation, placement accuracy, and clearance. A higher rating does not correct an unsuitable gripper or insufficient stroke.
Site requirements, safety evidence, and total ownership cost
Before installation, budget for more than the arm: mounting structure, foundations, anchoring, guarding, freight, GST, utilities, commissioning, training, and acceptance testing can sit outside the equipment-only price.
- Give the supplier the floor or column layout, available headroom, operating reach, load centre, cycle rate, and attachment weight. Confirm that the DRA-50 or DRA-80 rating covers the workpiece plus gripper; a 50 kg component with a 10 kg tool already exceeds a 50 kg usable payload.
- Prepare a level, load-bearing foundation and verify anchor details before delivery. Reserve the specified electrical supply, or provide clean compressed air with the required pressure, filtration, regulation, drainage, and leak checks.
- Request the machine risk assessment, preferably showing ISO 12100 risk-reduction work, rated-load data, anti-drop provisions, emergency-stop behaviour, pneumatic-failure behaviour, operating instructions, and maintenance instructions. Ask for a declaration of conformity or equivalent compliance document tied to the supplied machine.
- Put installation, commissioning, load testing, operator training, and acceptance criteria in the purchase order. Do not accept a quote that leaves the electrical panel, air-preparation unit, support column, rail, guarding, freight, or taxes undefined.
Service cost depends on balancing technology. A pneumatic system needs filter, regulator, seal, hose, and leak maintenance; an electric or servo-assisted unit can add drives, encoders, controls, and safety-circuit servicing. Price local response time, spare-seal availability, preventive-maintenance intervals, calibration, and load testing over the warranty period. Ask for both equipment-only and installed, commissioned totals.
How to compare Mumbai suppliers on an identical specification
Send every supplier the same application sheet before comparing a dra manipulator price in Mumbai. State the workpiece mass and dimensions, gripper mass, centre-of-gravity offset, required reach, vertical travel, rotation angle, cycle rate, acceleration, operating hours, and mounting location.
- Request the allowable payload at your specified reach and centre of gravity, not only “50 kg” or “80 kg”.
- Ask for the load chart or capacity-versus-reach table, including maximum load, working radius, vertical travel, allowable moment, and permitted load-centre offset.
- Specify whether the price includes the gripper, controls, pneumatic or hydraulic package, mounting structure, guarding, freight, installation, commissioning, operator training, and GST.
- Require separate equipment-only and installed, commissioned prices.
- Ask who performs commissioning and what load test, calibration record, drawings, manuals, and operator training you receive.
- Obtain preventive-maintenance intervals, seal and wear-part availability, and Mumbai response times.
| Price basis | Include in the quotation | Verify before acceptance |
|---|---|---|
| Equipment only | Arm, balancing system, controls, and stated attachment | Payload excludes no hidden gripper or tooling mass |
| Installed and commissioned | Equipment, structure, foundations, services, freight, installation, testing, training, and GST | Each inclusion is priced or marked “excluded” |
| Service support | Response time, spare parts, maintenance, calibration, and load testing | Named Mumbai contact and written turnaround commitment |
Whether you contact Hendo Industries, a dra 80 kg manipulator supplier in Mumbai, or a manipulator dealer near Mumbai, reject a headline figure that omits these boundaries. Two quotes are comparable only when their payload, reach, attachment, installation scope, and tax treatment match.
Related products
 | Manipulator The DRA-50 KGS Manipulator by Hendo Industries is a versatile and high-performance material handling solution designed to simplify lifting and... View product → |
 | Manipulator The DRA-80 KGS Manipulator by Hendo Industries is a robust and efficient material handling solution designed to streamline industrial operations. View product → |
Frequently asked questions
What should a DRA 50 or DRA 80 kg quotation include?
Request the equipment-only and installed, commissioned prices. The quotation should identify arm reach, vertical stroke, working envelope, balancing method, gripper, controls, mounting structure, freight, GST, and operator training.
How do you choose between a DRA-50 and DRA-80 manipulator?
Choose from the heaviest load the manipulator must lift, including the attachment and any offset. Confirm the working envelope and handling frequency rather than comparing rated capacity alone.
What should you check besides the manipulator's rated capacity?
Check reach, vertical stroke, rotation, controls, balancing response, attachment design, mounting arrangement, and whether a hoist, balancer, vacuum lifter, or another handling system suits the task better.
What site and safety information should a Mumbai supplier provide?
Ask for foundation or mounting requirements, available utilities, installation scope, load-test records, operating instructions, maintenance requirements, guarding details, and evidence that the complete installation has been commissioned safely.
How can you compare Mumbai manipulator suppliers fairly?
Send every supplier the same load dimensions, centre of gravity, lift height, reach, cycle rate, attachment requirements, mounting details, delivery location, and installation scope. Compare itemised totals rather than headline prices.
